AVSSX Automotive Wire – Super Thin-Wall XL-PVC 100°C Wire for High-Heat, Ultra-Compact Vehicle Wiring

AVSSX wire is a super thin-wall automotive cable insulated with cross-linked polyvinyl chloride (XL-PVC), manufactured to JIS C 3406 and JASO D611 standards. Commonly used in Japanese vehicles, its XL-PVC insulation offers excellent heat resistance, making it ideal for modern vehicles that require extremely compact, flexible, and lightweight wiring in areas with limited space and elevated temperatures.

Rated for 100°C and 60V, AVSSX wire features a significantly reduced insulation wall while maintaining mechanical strength and electrical reliability—especially in intricate engine compartments, complex door wiring, miniature lamps, and highly integrated electrical units where heat is a concern.

Key Features

Conductor: Stranded bare copper
Insulation: Super thin-wall cross-linked PVC (XL-PVC)
Temperature Rating: -40°C to 100°C
Voltage Rating: 60V (nominal automotive systems)
Wall Thickness: Thinner than AV/AVS wires, ideal for high-density harnesses
Color Coding: Available in solid and striped colors
RoHS Compliant: Lead-free and eco-friendly variants available

Common Applications

Compact vehicle wiring for lights, mirrors, switches near high-heat areas
Engine bay or dashboard wiring exposed to elevated temperatures
Dense connector harnesses in motorcycles and passenger vehicles
Small signal and power circuits in modern automotive electronic units

Conductor Resistance Reference (20°C, Ω/km)

Cross Section (mm²)	Resistance (Ω/km)
0.30	~65.5
0.50	~39.0
0.85	~23.0
1.25	~15.0
2.00	~9.5

🔗 Related Cable Types

🌐 Standards & Compliance

JASO D611 – Japanese automotive cable spec for low-voltage systems

Working with extremely tight spaces and high-temperature environments?

Let us help you select the best AVSSX wire for your demanding automotive application.
