AVSS Automotive Wire – Super Thin-Wall PVC 80°C Wire for Ultra-Compact Vehicle Wiring

AVSS wire is a super thin-wall automotive cable manufactured to JIS C 3406 and JASO D611 standards, commonly used in Japanese vehicles. It offers maximum space-saving insulation, making it ideal for modern vehicles that require extremely compact, flexible, and lightweight wiring in areas with highly restricted installation space.

Rated for 80°C and 60V, AVSS wire features a significantly reduced PVC insulation wall while maintaining mechanical strength and electrical reliability—especially in intricate dashboards, complex door wiring, miniature lamps, and highly integrated electrical units.

Key Features

Conductor: Stranded bare copper
Insulation: Super thin-wall lead-free PVC
Temperature Rating: -40°C to 80°C
Voltage Rating: 60V (nominal automotive systems)
Wall Thickness: Significantly thinner than AV and AVS wire for ultimate harnessing density
Color Coding: Available in solid and stripe colors for easy identification
RoHS Compliant: Environmentally safe manufacturing options available

Common Applications

Ultra-compact interior vehicle wiring for complex lighting, mirrors, and switches
Highly dense connector harnesses and extremely tight installation routes
Motorcycle and scooter electrical systems where space is at a premium
Miniature dashboard electronics and highly integrated ECU peripheral systems
Small power and signal circuits in advanced passenger vehicles

Conductor Resistance Reference (20°C, Ω/km)

Cross Section (mm²)	Resistance (Ω/km)
0.30	~65.5
0.50	~39.0
0.85	~23.0
1.25	~15.0
2.00	~9.5

🔗 Related Cable Types

🌐 Standards & Compliance

JASO D611 – Japanese automotive cable spec for low-voltage systems
