AVSSH Automotive Wire – Super Thin-Wall Heat-Resistant PVC 100°C Wire for Compact Automotive Applications
AVSSH wire is a super thin-wall automotive cable insulated with heat-resistant polyvinyl chloride (PVC). Compliant with JASO D611 and JASO D608 standards, AVSSH is designed for modern vehicles requiring compact, flexible, and thermally stable wiring solutions. Its PVC insulation offers enhanced heat resistance up to 100°C, making it suitable for high-density harnesses in areas with elevated temperatures and space constraints.
Key Features
-
Conductor: Stranded bare copper
-
Insulation: Super thin-wall heat-resistant PVC
-
Temperature Rating: -40°C to 100°C
-
Voltage Rating: 25V AC / 60V DC
-
Wall Thickness: Approximately 0.30 mm, optimized for ultra-compact harnesses
-
Color Coding: Available in solid and striped colors for circuit identification
-
RoHS Compliant: Lead-free, environmentally safe manufacturing
Common Applications
-
Interior vehicle wiring for dashboards, mirrors, door panels, and controls
-
Compact automotive connectors and high-density cable routing
-
Signal and low-power wiring in passenger cars and motorcycles
-
Lightweight harnesses for compact vehicles and scooters
-
Electrical modules where thermal stability and flame retardance are required
Conductor Resistance Reference (20°C, Ω/km)
| Cross Section (mm²) | Resistance (Ω/km) |
|---|---|
| 0.30 | ~48.6 |
| 0.50 | ~34.6 |
| 0.75 | ~23.6 |
| 1.25 | ~14.6 |
