UL3288 XLPE Insulated Wire – 150°C / 600V Hook-Up Wire for High-Temperature & Halogen-Free Applications
UL3288 is a high-temperature, high-voltage hook-up wire insulated with cross-linked polyethylene (XLPE) and certified under UL AWM Style 3288. Rated for continuous use at 150°C and up to 600V, this wire delivers excellent thermal performance, dielectric strength, and chemical resistance—ideal for demanding applications in electronics, energy, HVAC, and power control systems.
Its halogen-free and RoHS-compliant insulation makes it a preferred choice for manufacturers prioritizing environmental safety and low-smoke flame behavior.
Technical Specifications
-
Conductor: Solid or stranded bare/tinned copper
-
Size Range: 30 AWG to 4/0 AWG
-
Insulation: XLPE, nominal thickness 0.76 mm (30 mils)
-
Temperature Rating: 150°C
-
Voltage Rating: 600V AC / 750V DC
-
Flame Test: UL VW-1, CSA FT1 vertical flame test compliant
-
Compliance: UL 758 AWM, RoHS, REACH, Halogen-Free
Performance Benefits
-
Thermal Endurance: Designed for high-heat environments with stable insulation
-
Mechanical Strength: Resists abrasion, pulling, and compression
-
Chemical Resistance: Withstands oils, fuels, solvents, and moisture
-
Eco-Friendly: Halogen-free insulation supports clean combustion and reduced toxic smoke
-
Low Smoke Emission: Safer for confined spaces, control panels, and indoor systems
Application Areas
-
Internal wiring in control panels, switchgear, and energy storage systems (ESS/BBU)
-
Inverters, drives, and power modules in automation or renewable energy equipment
-
High-temperature wiring in medical devices, LED drivers, industrial motors, and lighting systems
-
Environmental control systems: HVAC, building automation, transportation electronics
Conductor Resistance Table (20°C, Ω/km)
| AWG | Resistance |
|---|---|
| 30 | 381 Ω/km |
| 26 | 150 Ω/km |
| 24 | 94.2 Ω/km |
| 22 | 59.4 Ω/km |
| 20 | 36.7 Ω/km |
| 18 | 23.2 Ω/km |
| 16 | 14.6 Ω/km |
| 14 | 8.96 Ω/km |
| 12 | 5.64 Ω/km |
| 10 | 3.55 Ω/km |
| 8 | 2.23 Ω/km |
| 6 | 1.40 Ω/km |
| 4 | 0.88 Ω/km |
| 2 | 0.55 Ω/km |
| 1 | 0.44 Ω/km |
| 1/0 | 0.28 Ω/km |
| 2/0 | 0.22 Ω/km |
| 3/0 | 0.17 Ω/km |
| 4/0 | 0.14 Ω/km |
