UL2785 PVC Insulated Cable – 80°C / 30V Parallel Wire for Internal Electronic Wiring
UL2785 is a UL-certified multi-conductor cable designed for the internal wiring of electronic equipment. Rated for 80°C and 30 V, UL2785 consists of two or more solid or stranded copper conductors laid parallel, insulated with extruded PVC, and optionally jacketed. It complies with the Cable Flame Test under UL 758 AWM standards, offering dependable flame resistance and flexibility for low-voltage applications.
Key Features
-
Conductor: Solid or stranded copper (two or more parallel)
-
Insulation: Extruded PVC
-
Jacket: Optional
-
Temperature Rating: 80°C
-
Voltage Rating: 30 V
-
Flame Resistance: Passes Cable Flame Test
-
Standard: UL 758 AWM Style 2785
-
Application: Internal wiring of electronic equipment only
Common Applications
-
Internal signal or power wiring in consumer electronics
-
Flat wire configurations in compact electronic devices
-
Flame-retardant, low-voltage parallel wiring for instruments and control modules
Conductor Resistance Reference (20°C, Ω/km)
| AWG | Resistance (Ω/km) |
|---|---|
| 26 | 13.70 |
| 24 | 8.62 |
| 22 | 5.44 |
