UL21120 – 600V / 80°C Multi-Conductor Cable with FRPE Jacket for Flexible and Spiral Applications

UL21120 is a UL-certified multi-conductor cable designed for both internal and external wiring of electronic equipment. Rated for 600V and 80°C, this cable features solid or stranded copper conductors, flame-retardant FRPE (Flame Retardant Polyethylene) insulation, and complies with the Cable Flame Test under UL 758 AWM standards. It is suitable for applications requiring flexibility and flame resistance.

 Key Features

• Conductor: High-purity tinned or bare copper strands (36 AWG and larger)

• Insulation: AWM-compliant material

• Jacket: Flame-retardant polyethylene (FRPE)

• Temperature Rating: 80°C

• Voltage Rating: 600V

• Dielectric Strength: 2000Vac for 60 seconds without breakdown

• Spark Voltage: 3KV

• Flame Resistance: Passes UL VW-1, FT1, and FT2 tests

• Standard: UL 758 AWM Style 21120

• Application: Internal and external wiring of electronic equipment

Common Applications

• Internal wiring in electronic devices

• External connections in industrial control systems

• Circuits requiring flame resistance and insulation durability

• High-reliability internal and external cabling for sensitive systems

Conductor Resistance Reference (20°C, Ω/km)

🔗 Related Products

• UL21143 – 600V / 80°C Multi-Conductor Cable

🌐 External Technical Reference

UL iQ™ Style Page – UL21120

Need help selecting the right cable?

Our technical team is ready to assist you in choosing the best UL21120 cable for your wiring needs.
👉 Contact Us | Request a Quote
