UL21064 – 80°C / 30V Halogen-Free FRPE Multi-Conductor Cable for Electronic Applications

UL21064 is a UL-certified multi-conductor cable designed for internal wiring of electronic equipment. Rated for 80°C and 30V, this cable features solid or stranded tinned copper conductors, flame-retardant FRPE (Flame Retardant Polyethylene) insulation, and complies with the Cable Flame Test under UL 758 AWM standards. It is suitable for applications requiring flexibility, flame resistance, and low smoke zero halogen (LSZH) properties.

 Key Features

• Conductor: Solid or stranded tinned copper (40 AWG to 20 AWG)

• Insulation: AWM-compliant material

• Shielding (Optional): Foil shield, braiding, or copper strands wrapped

• Jacket: Extruded FRPE (Flame Retardant Polyethylene), LSZH

• Temperature Rating: 80°C

• Voltage Rating: 30V

• Flame Resistance: Passes UL VW-1, FT1, and FT2 tests

• Standards: UL 758, UL 1581, UL 2556

• Compliance: RoHS, REACH, CE

• Application: Internal wiring of electronic equipment

Common Applications

• Internal wiring in electronic devices

• Circuits requiring flame resistance and insulation durability

• High-reliability internal cabling for sensitive systems

 Conductor Resistance Reference (20°C, Ω/km)
