UL20868 PVC Insulated Wire – 75°C 30V Flexible Cable for Internal Electronic Wiring
UL20868 is a UL-certified wire designed for internal wiring in electronic and electrical equipment. Rated for 75°C and 30V, this cable features PVC insulation, providing reliable performance and protection in compact or low-voltage electronic systems. With its flame-retardant properties and flexibility, it is particularly suitable for intricate circuit designs and panel applications.
Key Features
-
Conductor: Solid or stranded copper
-
Insulation: UL-labeled PVC
-
Temperature Rating: Up to 75°C
-
Voltage Rating: 30V
-
Flame Resistance: Passes UL Cable Flame Test
-
Standards: Complies with UL 758 Appliance Wiring Material (AWM) Style 20868
Common Applications
-
Internal wiring in electronic devices, instrument panels, and consumer appliances
-
Compact circuits requiring flexible, flame-retardant, and low-voltage insulation
-
Ideal for OEMs producing low-voltage communication, testing, and data equipment
Conductor Resistance Reference (20°C, Ω/km)
| AWG | Resistance (Ω/km) |
|---|---|
| 30 | 34.6 |
| 28 | 21.8 |
| 26 | 13.7 |
| 24 | 8.62 |
| 22 | 5.44 |
| 20 | 3.42 |
| 18 | 2.15 |
| 16 | 1.36 |
| 14 | 0.86 |
| 12 | 0.54 |
| 10 | 0.34 |
