UL20744 Flat Ribbon Cable – 60/80°C, 30/150V Bonded or Laminated for Internal Electronic Wiring

UL20744 is a UL-certified flat ribbon cable designed for the internal wiring of electronic equipment. Rated for 60°C or 80°C and 30V or 150V, this cable features 2 to 200 insulated singles (twisted pairs, triads, or quads) laid parallel in one plane, intermittently or continuously bonded together or to the PVC covering to form a flat ribbon type cable. It complies with the Horizontal Flame Test under UL 758 AWM standards, making it suitable for applications requiring flexibility and flame resistance.

Key Features

• Conductor: Solid or stranded copper, 36–10 AWG

• Insulation: PVC or as per manufacturer's AWM procedure

• Assembly: 2–200 insulated singles (twisted pairs, triads, or quads) laid parallel in one plane, bonded or laminated

• Inner Covering: Optional, extruded PVC or laminated PVC/polyester film

• Shield: Optional

• Outer Covering: Optional, PVC (5–80 mils), PTFE (2–80 mils), or polyester film

• Temperature Rating: 60°C or 80°C

• Voltage Rating: 30V or 150V

• Flame Resistance: Passes Horizontal Flame Test

• Standard: UL 758 AWM Style 20744

• Application: Internal wiring of electronic equipment

Common Applications

• Internal wiring in electronic devices

• Data transmission in computers and peripherals

• Signal wiring in industrial equipment

• Applications requiring flat ribbon cable configurations

Conductor Resistance Reference (20°C, Ω/km)
